Zebra LS2208 Bar Code Reader - Wired - Linear
Type |
Value |
Additional Information |
Supported Interfaces: - Serial
- Keyboard Wedge
- Wand Emulation
- IBM 468X/469X
- USB
- Synapse
USB Cable separate |
Application/Usage |
Education |
Barcode Symbology Supported |
- UPC/EAN
- UPC/EAN Supplementals
- UCC/EAN 128
- Code 39
- Code 39 Full ASCII
- Code 39 TriOptic
- Code 128
- Code 128 Full ASCII
- Codabar
- Interleaved 2 of 5
- Discrete 2 of 5
- Code 93
- MSI
- Code 11
- IATA
- RSS Variants
- Chinese 2 of 5
|
Brand Name |
Zebra |
Cable Type Included |
USB |
Certifications & Standards |
- Environmental: RoHS 2002/95/EEC
Electrical Safety: - UL1950
- CSA C22.2 No. 950
- EN60950/IEC950
EMI/RFI: - FCC Part 15 Class B
- ICES-003 Class B
- European Union EMC Directive
- Australian SMA
- Taiwan EMC
- Japan VCCI/MITI/Dentori
Laser Safety:: |
Color |
White |
Compatibility |
|
Connectivity Technology |
Cable |
Country of Origin |
Mexico |
Depth |
3.3" |
Drop Specification |
Unit functions normally after repeated 5 ft./1.5 m drops to concrete |
Environmental Certification |
RoHS |
Environmentally Friendly |
Yes |
Form Factor |
Handheld |
Height |
6" |
Host Interface |
USB |
Image Sensor Type |
Linear |
Ingress Protection (IP) Rating |
IP30 |
Input Voltage |
5 V DC |
Light Source |
Laser |
Limited Warranty |
5 Year |
Manufacturer |
Zebra Technologies Corporation |
Manufacturer Part Number |
LS2208-SR20001R-UR |
Manufacturer Website Address |
http://www.zebra.com |
Marketing Information |
OUR BEST SELLING HANDHELD LASER SCANNER
With over eight million sold, the LS2208 remains our best selling handheld laser scanner. The LS2208 has it all - enterprise class scanning in a very ergonomic and durable lightweight design that delivers all day comfort, an extra-long read range for easy scanning, plus support for everyday 1D bar codes, including high-density. With multiple interfaces, a universal cable and support for keyboards in 97 languages, the LS2208 delivers plug-and-play simplicity in virtually every corner of the world. The LS2208 - the well-proven scanner powering the checkout lines all around the world.
Durable construction With its patented single board construction, patented frictionless liquid polymer scan element, scratch resistant tempered glass exit window and a stringent drop and tumble specification, the LS2208 delivers reliable all-day, every day operation.
Capture high-density bar codes for greater application flexibility With just one scanner, you can capture the high density bar codes common on small items.
Deploy in every corner of the world With support for 97 international keyboards, the LS2208 is ready for operation in your country, right out of the box.
Class-leading working range Workers can capture everyday 13 mil UPC bar codes on items that are over 25 in./63.5 cm away, improving productivity and the customer checkout experience.
Class-leading working range Workers can capture everyday 13 mil UPC bar codes on items that are over 25 in./63.5 cm away, improving productivity and the customer checkout experience.
All day comfort your workers can count on The well-proven ergonomic and lightweight balanced design provides maximum comfort, even in the most scan intensive environments. The result? Reduced user fatigue and increased worker productivity.
Flexible handheld or hands-free operation The optional IntellistandTM enables presentation scanning and allows workers to automatically switch between hands-free and handheld modes in the time it takes to drop the LS2208 into the stand.
Multiple interfaces No matter what host you need to connect to today or tomorrow, the future proof LS2208 is ready.
Truly plug-and-play The universal cable connects to any computing environment, practically eliminating setup and training time.
Advanced Data Formatting (ADF) Format data properly before it is sent to your host computer, eliminating the costly modification of host software. |
Maximum Ambient Light |
86111 lux |
Maximum Element Resolution (C |
40 mil |
Minimum Element Resolution (C |
5 mil |
Minimum Print Contrast |
20% |
Package Contents |
- Symbol LS2208 Bar Code Reader
- USB Cable
- Gooseneck Stand
|
Platform Supported |
PC |
Product Model |
LS2208 |
Product Name |
LS2208 Barcode Scanner Kit |
Product Type |
Barcode Scanner Kit |
Reading Angle (Pitch) |
65° |
Reading Angle (Roll) |
30° |
Reading Angle (Skew) |
60° |
Scan Pattern |
Bi-directional |
Scan Rate |
100 scan/s |
Scanning Capability |
1D |
Scanning Distance |
29.92" |
Stand Included |
Yes |
Weight (Approximate) |
5.15 oz |
Width |
2.5" |
Zebra LS2208 Bar Code Reader - Wired - Linear
