ATEN DVI HDBaseT KVM Extender with ExtremeUSB-TAA Compliant

Item #: 9U7018   |   Model #: 0672792007163

  |   10 Questions
Regular price
$1,161.00
Sale price
$1,161.00
Regular price
Sold out
Unit price
per

1 Each

Special Buy

ATEN DVI HDBaseT KVM Extender with ExtremeUSB-TAA Compliant - 1 Computer(s) - 1 Remote User(s) - 328.08 ft Range - WUXGA - 1920 x 1200 Maximum Video Resolution - 2 x Network (RJ-45) - 6 x USB - 2 x DVI - 5 V DC Input Voltage - Rack-mountable - For PC, Mac, Linux
Type Value
Brand Name Aten
Connectivity Technology Wired
Country of Origin Taiwan
DVI Yes
Environmental Certification WEEE
Environmentally Friendly Yes
Form Factor Rack-mountable
Graphic Mode WUXGA
Input Voltage 5 V DC
Manufacturer ATEN Technology Inc
Manufacturer Part Number CE610A
Manufacturer Website Address http://www.aten.com/us/en/
Marketing Information

The CE610A USB DVI KVM Extender is a DVI and USB Extender that supports ExtremeUSB ® and HDBaseT technology. The CE610A can extend DVI and USB 2.0 signals up to 300 ft (100 m) from the source using a single Cat 5e/6 cable.

The CE610A is equipped with USB connectors which allow you to extend any USB device between the units. The USB functionality provides not only peripheral sharing but also the support for touch panel control and fi le transfer. The CE610A is ideal for situations where touch panel is required, such as transportation centers, medical facilities, shopping malls, industrial kiosks, and when synchronizing for files / folders between portable and desktop computers are required.

Maximum Operating Distance 328.08 ft
Maximum Video Resolution 1920 x 1200
Network (RJ-45) Yes
Number of Computers Supported 1
Number of DVI Ports 2
Number of Network (RJ-45) Por 2
Number of Remote Users Suppor 1
Number of USB Ports 6
Package Contents
  • 1 x CE610AL DVI HDBaseT KVM Extender with ExtremeUSB (Local Unit)
  • 1 x CE610AR DVI HDBaseT KVM Extender with ExtremeUSB (Remote Unit)
  • 1 x Custom DVI Cable (DVI Dual Link; 1.8m/6ft)
  • 1 x USB Cable (1.8m/6ft)
  • 2 x Power Adapters
  • 1 x Mounting Kit
  • 1 x User Instructions
Platform Supported Linux
Power Consumption 15 W
Product Model CE610A
Product Name DVI HDBaseT KVM Extender with ExtremeUSB
Product Type KVM Console/Extender
Receiver Depth 7.17"
Receiver Height 1.13"
Receiver Weight (Approximate) 1.37 lb
Receiver Width 4.64"
Transmitter Depth 7.17"
Transmitter Height 1.13"
Transmitter Weight (Approxima 1.37 lb
Transmitter Width 4.64"
USB Yes
ATEN DVI HDBaseT KVM Extender with ExtremeUSB-TAA Compliant - 1 Computer(s) - 1 Remote User(s) - 328.08 ft Range - WUXGA - 1920 x 1200 Maximum Video Resolution - 2 x Network (RJ-45) - 6 x USB - 2 x DVI - 5 V DC Input Voltage - Rack-mountable - For PC, Mac, Linux
