Eaton Tripp Lite Series HDMI over IP Extender Receiver - 4K UHD, PoE, 328 ft (100 m)

Eaton Tripp Lite Series HDMI over IP Decoder - 4K, 4:4:4, PoE, 328 ft. (100 m), TAA

The Eaton Tripp Lite B162-100-POE is a high-performance HDMI over IP extender receiver designed for seamless 4K video transmission over long distances. Supporting visually lossless 4K signals at 60 Hz with low latency, this device can extend video signals up to 328 feet (100 meters) via a standard Gigabit Ethernet switch. Its advanced video lossless compression technology ensures high-quality output with minimal delay, making it ideal for large-scale digital signage, conference rooms, airports, and other indoor environments that require crisp, high-resolution displays. The device supports three levels of video compression—Smooth, Balance, and High Quality—allowing users to optimize performance based on their specific application needs. LEDs on the unit indicate connection and power status, simplifying troubleshooting and setup. The B162-100-POE is compatible with Tripp Lite’s B162-001-POE transmitter, enabling flexible configurations in multipoint-to-multipoint setups without distance limitations. Its support for Power over Ethernet (PoE) allows the device to be powered through a shielded Cat6 cable, reducing the need for additional power supplies and enabling installation in hard-to-reach areas such as ceilings or high-mounted wall positions. When connected to a PoE switch, the receiver can be integrated into scalable, flexible video distribution networks suitable for large venues like shopping centers, hotels, and expo centers. The device features web-based management via the built-in GUI, allowing configuration, status monitoring, and layout management directly from a browser without extra software. Additionally, it supports spontaneous scheduling, enabling pre-programmed display schedules, event management, and grouping of multiple devices for synchronized content delivery. The simple, intuitive operation requires no extensive IT expertise, with input source switching accomplished via buttons on the top panel. Its daisy-chain capability supports linking up to 30 units through a network switch, facilitating extensive video wall configurations such as 8 x 8 layouts. The compact, desktop form factor combined with mounting options makes deployment straightforward. Certified TAA compliant and environmentally friendly, the B162-100-POE is built in Taiwan and backed by a one-year limited warranty, offering reliable performance for mission-critical digital signage and presentation applications.

Features:

• Supports visually lossless 4K video at 60 Hz with low latency for high-quality image transmission

• Advanced lossless compression technology allows three adjustable levels: Smooth, Balance, and High Quality

• Supports Power over Ethernet (PoE) for flexible installation and reduced cabling costs

• Extends video signals up to 328 feet (100 meters) over standard Gigabit Ethernet switches

• Compatible with Tripp Lite B162-001-POE transmitters for multipoint-to-multipoint setups

• Web GUI management provides easy configuration, status monitoring, and display layout control

• Supports spontaneous scheduling for pre-programmed display and event management

• Simple input source switching via top panel buttons requires no extensive IT knowledge

• Daisy-chain support for up to 30 units enables large-scale video wall deployment

• Supports 4K @ 30 Hz resolution with HDMI 2.0 compatibility for crisp, detailed images
