Honeywell QuantumT MS3580 Bar Code Reader

Item #: F59510   |   Model #: 9999999999999

  |   10 Questions
$519.54
$519.54
Sold out

1 Each

Special Buy
Add to list
Type Value
Additional Information

Supported Interfaces:

  • Serial
  • Light Pen Emulation
  • Keyboard Wedge
  • IBM 468X/469X
  • USB
  • OCIA
  • Laser Emulation

USB Cable separate
Application/Usage Retail
Barcode Symbology Supported
  • All Standard 1D Symbologies
  • RSS-Expanded
  • RSS-14
  • RSS-14 Limited
Brand Name Honeywell
Cable Type Included USB
Certifications & Standards

Laser Class:

  • Class 1; IEC60825-1:1993/A1:1997+A2:2001
  • Class 1; EN60825-1:1994/A11:1996+A2:2001

EMC:

  • FCC, ICES-003 & EN55022 Class A
Color Black
Connectivity Technology Cable
Depth of Field
  • 1.5" - 4"@5.2mil
  • 0.8" - 7.3"@7.5mil
  • 0.8" - 9.3"@10.4mil
  • 0.8" - 10"@13mil
  • 0.8" - 11.8"@26mil
Drop Specification Designed to withstand 1.5 m (5�) drops
Form Factor Desktop
Height 4.3"
Host Interface USB
Input Voltage 5 V DC
Length 2.6"
Light Source Laser
Manufacturer Honeywell International, Inc
Manufacturer Part Number MK3580-31A38
Manufacturer Website Address http://www.honeywell.com
Marketing Information

Honeywell's QuantumT® 3580 provides retailers with industry-leading omnidirectional scan performance and optional single-line scanning in a convenient size. The small footprint and numerous stand options for QuantumT minimize required counter space, increasing available room for merchandise and advertisement displays.

Ideal for presentation scanning in moderate-volume retail environments such as convenience stores, liquor stores and pharmacies, end users can individually customize the scan pattern and operate the scanner in either a hand-held or hands-free fashion. In addition, its rugged, rubber housing provides the necessary protection against daily operational use.
Maximum Ambient Light 4842 lux
Maximum Scan Resolution 5 mil
Minimum Print Contrast 35%
Package Contents
  • QuantumT MS3580 Bar Code Reader
  • Rubber Boot mounted on plastic base
  • Cable
  • Manuals
Product Line QuantumT
Product Model MS3580-38
Product Name QuantumT 3580 Omnidirectional Laser Scanner
Product Type Barcode Scanner
Reading Angle (Pitch) 60°
Reading Angle (Skew) 60°
Rugged Yes
Scan Pattern Single Line
Scan Rate 1650 scan/s
Scanning Capability 1D
Scanning Distance 11.73"
Weight (Approximate) 6 oz
Width 2.7"
