ContactRaritan Dominion KX IV-101 Ultra High Performance 1-Port 4K KVM-over-IP Switch
Item #: 5526542 | Model #: 0785813077509
| 10 Questions
| Type | Value |
|---|---|
| Brand Name | Raritan |
| Country of Origin | Taiwan |
| Depth | 5.7" |
| Form Factor | Rack-mountable |
| HDMI | Yes |
| Height | 1.2" |
| Limited Warranty | 2 Year |
| Manufacturer | Legrand Group |
| Manufacturer Part Number | DKX4-101 |
| Manufacturer Website Address | http://www.legrand.us |
| Marketing Information | Dominion KX IV-101 - Raritan's fourth generation single-port KVM-over-IP switch Gateway, provides a new level of Ultra HD performance for KVM-over-IP remote management. More powerful than any other KVM-over-IP switch, it supports unblocked, Java-free anytime / anywhere, BIOS-level remote access of servers, PCs and workstations. The KX IV connects to a single computer, providing unblocked access to multiple users via laptop, PC or Dominion User Station. The KX IV-101 supports access to servers with 4K video resolution (3840x2160), up to 30 frames per second with 4:2:2 color. It also supports HD resolutions up to 1920x1080 and 1920x1200 at up to 60 frames per second with high quality 4:4:4 color. The KX IV has an all-digital architecture for ultra fast video performance and high video quality, with virtual media transfers up to 3 times faster than the Dominion KX III. The KX IV has user-configurable bandwidth to operate across LAN, WAN and Internet. The KX IV supports many of the popular Dominion features such as: virtual media, absolute mouse synchronization, LDAP/Radius/AD authentication, AES encryption, support for up to 8 simultaneous sessions, and much more. Users can use the Dominion KVM Clients for Java-free access, as well as the Dominion KX User Stations for high performance access in labs, studios and control rooms. Dominion KX IV is incredibly scalable. A large number of KX IV switches can be integrated through the Dominion User Station and/or Raritan's CommandCenter Secure Gateway, with convenient single sign-on. The powerful Dominion User Station works standalone or with CommandCenter. Raritan DKX4-101 Features
Raritan DKX4-101 Highlights The Broadest Array of Video Support in a Single-Port IP KVM The most compatible IP KVMs in the market, the Dominion KX4-101 Over-IP Gateways support: |
| Maximum Video Resolution | 4096 x 2160 |
| Network (RJ-45) | Yes |
| Number of Computers Supported | 1 |
| Number of HDMI Ports | 2 |
| Number of Local Users Support | 1 |
| Number of Network (RJ-45) Por | 1 |
| Number of USB Ports | 3 |
| Package Contents |
|
| Packaged Quantity | 1 |
| Product Line | Dominion |
| Product Model | KX IV-101 |
| Product Name | Dominion KX IV-101 Ultra High Performance 1-Port 4K KVM-over-IP Switch |
| Product Type | KVM Switchbox |
| Rack Height | 1U |
| USB | Yes |
| Weight (Approximate) | 1.43 lb |
| Width | 5.5" |
