StarTech.com 10m (33ft) LC/UPC to SC/UPC OM3 Multimode Fiber Optic Duplex Cable - Aqua, 10 Gbps, LSZH Jacket

StarTech.com 10m (30ft) LC/UPC to SC/UPC OM3 Multimode Fiber Optic Cable, Full Duplex 50/125 Zipcord, 100G, LSZH Fiber Jumper Cord

The StarTech.com 10Gb Fiber Optic Duplex Cable (Part Number: A50FBLCSC10) provides a high-performance solution for demanding network environments. Designed with 50/125 micron OM3 aqua fiber, this cable ensures reliable data transmission at speeds up to 10 Gbps, making it ideal for backbone connections between switches, routers, and high-end networking equipment. Its full-duplex design and multimode configuration support bandwidth-intensive applications such as SANs, data servers, and high-speed data centers, supporting various standards including 100GBASE-SR10 and 10GBASE-SR. The cable features LC and SC connectors with UPC polished ceramic ferrules, ensuring low insertion loss below 0.3dB and optimal signal integrity. The cable's construction includes a protective Aramid fiber sheath for enhanced tensile strength and crush resistance, and a low-smoke, zero-halogen (LSZH) jacket that minimizes toxic fumes and smoke in case of fire, aligning with safety regulations for industrial, commercial, and residential settings. This flexible cable boasts a bend radius suitable for tight installations and is individually tested for quality and performance. It is backward compatible with OM2 fiber, offering versatility for diverse network infrastructures. With a length of approximately 33 feet, the cable is perfect for extending high-speed connections across different network segments. Backed by a lifetime warranty, the StarTech.com fiber optic cable combines durability, safety, and high-speed performance for professional networking applications.

Features:

• Specs: 10m (33ft); Color: Aqua (OM3); LC/SC UPC; 850nm or 1300nm LED/VCSEL; Modal Bandwidth: ≥2000MHzkm at 850nm; Cable OD: 2.9mm; Bend Radius: Static 1.2in (3cm), Dynamic 2.4in (6cm); Backed for Life

• Compatibility: Supports 1/10/40/100 Gbps for high-density network applications such as SANs, data servers, SFP+ and QSFP+ connections over 1000BASE-SX, 10GBASE-SR, 40GBASE-SR4, and 100GBASE-SR10; Backward compatible with OM2

• Ratings and Reliability: Individually tested for signal integrity; LSZH jacket emits low-smoke and fumes in case of fire; TIA/EIA compliant fiber core; Attenuation value under 2.3dB/km meets or exceeds industry standards

• Quality Construction: 50/125µm fiber core/cladding immune to EMI; Protective Aramid fiber sheath for improved tensile strength and crush resistance; LC/SC connectors with UPC polished ceramic ferrules for insertion loss below 0.3dB

• OM3 Fiber Cable: Laser-Optimized Multimode Fiber delivers up to 100 Gbps Ethernet; Full-duplex design for high-speed, reliable data transfer
